PLATIC MOULD STEELS
Steels with a high wear resistance, good polishability, etching ability, sufficient corrosion resistance and cost-efficient machining properties are required to manufacture plastic parts.
PLASTIC MOULD STEELS GALLERY
Grade | % | C | Mn | Si | Ni | cr | Mo | S | P |
---|---|---|---|---|---|---|---|---|---|
P20 | Min | 0.28 | 0.60 | 0.20 | 1.40 | 0.30 | Max | Max | |
Max | 0.40 | 1.00 | 0.80 | 2.00 | 0.55 | 0.015 | 0.02 |
Grade | % | C | Mn | Si | Ni | cr | Mo | S | P |
---|---|---|---|---|---|---|---|---|---|
DIN 1.2311 | Min | 0.35 | 1.40 | 0.30 | 1.8 | 0.2 | Max | Max | |
Max | 0.45 | 1.60 | 0.50 | 2 | 0.3 | 0.015 | 0.02 |
Grade | % | C | Mn | Si | Ni | cr | Mo | S | P |
---|---|---|---|---|---|---|---|---|---|
DIN 1.2378 | Min | 0.35 | 1.40 | 0.32 | 0.95 | 1.80 | 0.20 | Max | Max |
Max | 0.45 | 1.60 | 0.50 | 1.10 | 2.00 | 0.30 | 0.015 | 0.02 |
Application :
Moulds for Plastic injection Moulding and Die casting.
