ANNEALED STEEL STRIPS
C45 , C-62 , C-75 and EN 47 GRADES
This grade of steel strips are not commonly used in India , so it is not in our inventory but we do supply against an specific request from customer Minimum order quantity and lead time for delivery depends on size
C-45 GRADE
This grade of strip is used where toughness is required but elasticity is not important Because of lower Carbon contents it offers better forming and bending quality
C62 GRADE
This grade offers reasonably good fatigue value and elastic limity after hardening and tempering and compares with C65, CK67 grades
EN47/ 50 CRV4
This grade offers good bending and forming properties and is less sensitive to surface de carburisation while heat treatment it also resists deformation during hardening and tempering
page - 1
GRADEN | CARBON | MANGANESE | SILICON | SULPHUR | PHOSPHORUS | CR | Vanadium |
---|---|---|---|---|---|---|---|
C-45 | 0.40-0.50% | 0.00-0.90% | 0.10-0.35% | 0.05%MAX | 0.05%MAX | ||
C-55 | 0.50-0.6% | 0.00-0.90% | 0.35% MAX | 0.05%MAX | 0.05%MAX | ||
C-75 | 0.70-0.80% | 0.00-0.90% | 0.35% MAX | 0.05%MAX | 0.05%MAX | ||
C-80 | 0.75-0.85% | 0.00-0.90% | 0.10-0.35% | 0.05%MAX | 0.05%MAX | ||
50CrV4 | 0.45-0.55% | 0.50-0.80% | 0.10-0.35% | 0.05%MAX | 0.05%MAX |
